No. |
Part Name |
Specification |
|
1 |
Body |
Ductile Iron GGG50 |
|
2 |
Wedge |
Ductile Iron GGG50 |
|
3 |
Wedge Coating |
NBR /EPDM EN 681-1 |
|
4 |
Wedge Nut |
Copper Alloy |
|
5 |
Stem |
Stainless Steel X20 Cr13 |
|
6 |
Bonnet Gasket |
NBR /EPDM EN 681-1 |
|
7 |
Bonnet |
Ductile Iron GGG50 |
|
8 |
O Ring Back Sealing |
EPDM/NBR |
|
9 |
Down Bushing |
Copper Alloy |
|
10 |
O Ring |
EPDM/NBR |
|
11 |
Stem Collar |
Stainless Steel / Brass |
|
12 |
O-Ring |
EPDM/NBR |
|
13 |
O-Ring |
EPDM/NBR |
|
14 |
Gland Flange |
Ductile Iron GGG50 |
|
15 |
Stuffing Cork |
Copper Alloy |
|
16 |
Dust Guard |
EPDM/NBR |
|
17 |
HandWheel |
Ductile Iron GGG50 |
|
18 |
Stem Cap |
Ductile Iron GGG50 |
|
|
L |
|
|
EN 1092-2 PN10 |
EN 1092-2 PN16 |
|
|
W.T(kg ) |
||||||
|
F4 |
F5 |
D1 |
D2 |
n-d |
D1 |
D2 |
n-d |
F4 |
F5 |
|||||
|
DN350 |
290 |
550 |
520 |
26.5 |
460 |
429 |
16-23 |
470 |
429 |
16-28 |
762 |
450 |
175 |
220 |
|
DN400 |
310 |
600 |
580 |
28 |
515 |
480 |
16-28 |
525 |
480 |
16-31 |
836 |
450 |
223 |
290 |
|
DN450 |
330 |
650 |
640 |
30 |
565 |
530 |
20-28 |
585 |
548 |
20-31 |
957 |
640 |
322 |
420 |
|
DN500 |
350 |
700 |
715 |
31.5 |
620 |
582 |
20-28 |
650 |
609 |
20-34 |
1036 |
640 |
365 |
470 |
|
DN600 |
390 |
800 |
840 |
36 |
725 |
682 |
20-31 |
770 |
720 |
20-37 |
1188 |
640 |
539 |
700 |
|
DN700 |
430 |
900 |
910 |
39.5 |
840 |
794 |
24-31 |
840 |
794 |
24-37 |
1450 |
800 |
700 |
910 |
|
DN800 |
470 |
1000 |
1025 |
43 |
950 |
901 |
24-34 |
950 |
901 |
24-41 |
1660 |
1000 |
950 |
1235 |
|
DN1000 |
550 |
1200 |
1255 |
50 |
1160 |
1112 |
28-37 |
1170 |
1112 |
28-44 |
2100 |
1000 |
1400 |
1820 |
